The CO2 sensor is a sensor for a wide range of applications. In combination with e.g. MultiController it could be used for full control of ventilation in a single room and/or as CO2 sensor in more complicated ventilation systems.
The CO2 sensor is provided with a 0-10V proportional output based on the current CO2 level to be used as input signal for the controller of a damper or ventilation plant.
In addition, this model has a built in NTC 22Kohm sensor for simultaneously measurement of temperature in the duct.
Both design and ease-of-use have been prioritised.
In combination with our 24V DC power supply type PowerSupply 0.1-24E with integrated set point relay a very easy implemented on/off operation is achieved. For more fine-tuned regulation LS Control recommend using the MultiController E Regulate or MultiController E 0-100%.
CO2 Sensor uses the widely used ABC algorithm, which ensures long life without calibration. Only the room cannot be used constantly, but must regularly get sufficient airflow to lower the CO2 to fresh air level.
