Basic Regulate Temperature / ES 1090

Item no.: 44100

View dealers
Support If you have questions or need assistance in choosing amongst or using our products, please do not hesitate to contact customer service:

Regulator with build-in temperature sensor and alarm-lamp. The regulator regulates eg. a ventilator, damper or other equipment using a 0-10V control signal. Temperature can be adjusted in the range 14-27°C

Basic regulate is equipped with a green light for operation and a red light for warnings from Tacho-signal from EC-motor / Ventilator or a pressure switch monitoring the filter.

Power outlet

230 V

Size (HxWxD)

85x85x30 mm

Frequency

50 Hz

Max. tolerance of supply

10%

EAN Number

5703471441000

Number of 0-10V Outputs

1

Enclosure

IP 20

Ambient Operating Temperature

0 – 40 °C

Power Supply

230 VAC

0-10V Output Current

5 mA

Guide for BasicRegulate Temperature / ES 1090
Declaration of Conformity (Danish only)
